Montero LTD 4WD V6-3.5L SOHC (2002)
Steering Gear: Specifications
Gear box assembly installation bolt
69 +/- 10 Nm
Gear box clamp installation bolt
69 +/- 10 Nm
Steering gear and joint assembly connection
18 +/- 2 Nm
Power steering gear box
Type
Rack and pinion
Gear ratio
45.95
Steering gear retention hydraulic pressure
Standard Value 8.3 - 9.0 MPa
Gear box total pinion torque
Standard Value 0.6 - 1.7 Nm
Change in torque: 0.7 Nm (6.1 inch lbs.) or less
