Montero SR 4WD V6-3.5L DOHC (1995)
Sunroof / Moonroof Switch: Technical Service Bulletins
Sunroof Power Supply Connector - Color Change
NO.: TSB-96-54-006
Date: June, 1996
MODEL: 1995 Montero
SUBJECT:
CHANGE IN COLOR OF SUNROOF POWER SUPPLY CONNECTOR SERVICE MANUAL REVISION
PURPOSE
On February 1, 1995, the factory changed the color of the sunroof power supply connector from white to black. This bulletin contains the corrected
configuration diagram.
Write the TSB revision number of this bulletin in the "TSB Revision" box at the bottom of the affected service manual page.
AFFECTED VEHICLES
1995 Montero
