Crankshaft Main Bearing: Specifications

Bank stiffener bolt ..........................................................................................................................................................................  23 ± 6 N·m (17 ± 4 ft-lb)
Bearing cap bolt .....................................................................................................................................................................  24 ± 2 N·m (18 ± 1 ft-lb) +90°

Crankshaft end play mm (in)
Standard value ..............................................................................................................................................................................  0.05 - 0.25 (0.002 - 0.009)
Limit .......................................................................................................................................................................................................................  0.3 (0.01)

Crankshaft journal outside diameter mm (in) ............................................................................................................................................................  69 (2.7)

Crankshaft pin outside diameter mm (in) ..................................................................................................................................................................  53 (2.1)

Crankshaft journal oil clearance mm (in)
No.1, 4 journal
Standard value ....................................................................................................................................................................... 0.018 - 0.038 (0.0008 - 0.0014)
Limit ...................................................................................................................................................................................................................... 0.1 (0.004)
No.2, 3 journal
Standard value ....................................................................................................................................................................... 0.024 - 0.044 (0.0010 - 0.0017)
Limit ...................................................................................................................................................................................................................... 0.1 (0.004)
