Pickup 4WD L4-2555cc 2.6L SOHC (1984)
Emissions Maintenance Light: Service and Repair
Maintenance Reminder Lamp
An EGR warning lamp on the dash will illuminate at 50,000 miles to alert the driver to have EGR system inspected and serviced.
Fig. 1 Resetting EGR Maintenance Reminder Lamp
Fig. 2 Resetting EGR/maintenance Required Reminder Lamp
Resetting EGR/maintenance Required Reminder Lamp
Following inspection and maintenance, reset mileage sensor. Reset switch is located on the back of instrument panel either to the left of or below
speedometer cable junction, Figs. 1 through 3. Slide switch to the opposite position to reset sensor lamp.
