Flywheel: Specifications

TIGHTENING SPECIFICATIONS

Mounting Bolts  .....................................................................................................................................................................  83 - 93 Nm (61 - 69 ft. lbs.)

DIMENSIONS

Runout [1] ...................................................................................................................................................................  Less Than 0.15 mm (0.0059 inch)

[1] Total indicator reading 145 mm (5.71 inch) from the crankshaft center.
