Sentra L4-1.8L (QG18DE) (2004)
Alignment: Specifications
Rear Suspension
Rear Wheel Alignment (Unladen*)
Camber Degree minute (Decimal degree)
Minimum ............................................................................................................................................................................................... -1°45'(-1.75°)
Nominal ................................................................................................................................................................................................. -1°00'(-1.00°)
Maximum .............................................................................................................................................................................................. -0°15'(-0.25°)
Total toe-in
Distance (A- B)
Minimum .................................................................................................................................................................................. -3 mm (-0.12 inch)
Nominal ...................................................................................................................................................................................... 1 mm (0.04 inch)
Maximum .................................................................................................................................................................................... 5 mm (0.20 inch)
Angle (left plus right) Degree minute (Decimal degree)
Minimum ............................................................................................................................................................................................ -16' (-0.27°)
Nominal .............................................................................................................................................................................................. 5'30" (0.09 )
Maximum .............................................................................................................................................................................................. 26' (0.43°)
Ride Height (Unladen*)
*: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
