Ball Joint: Specifications
- Make
- Nissan and Datsun
- Model
- Sentra
- Engine
- L4-2.5L (QR25DE)
- Year
- 2003
- Section
- Suspension › Ball Joint › Specifications
Steering and SuspensionSpecifications · page 1 of 2
/Page-1805001.png)
Ball Joint: Specifications
Lower Ball Joint
Swinging force "A" (Measuring point: cotter pin hole of ball stud) N (kg, lbs.); 7.8 - 77.5 N (0.8 - 7.9kg. ,1.8 - 17.4 lbs.)
Turning torque "B"; 0 50 - 4.90 Nm (5.1 - 50.0 kg-cm ,4.4 - 43.4 inch lbs.)
Vertical end play "C" ................................................................................................................................................................................. 0 mm (0 inch)
