Timing Belt: Service and Repair

Make

Plymouth

Model

Laser

Engine

L4-1753cc 1.8L SOHC

Year

1991

Section

Timing Belt › Service and Repair

MaintenanceService and Repair · page 1 of 11

Timing Belt: Service and Repair

Removal steps

1. Clamp for pressure hose (power steering)

2. Engine mount bracket

3. Drive belt (power steering)

4. Tensioner pulley bracket

5. Drive belt (air conditioning)

6. Drive belt (generator)

7. Water pump pulley (power steering)

8. Water pump pulley

9. Damper pulley

10. Adapter

11. Crankshaft pulley

12. Timing belt front upper cover
