Drive Belt: Specifications
Belt Deflection

Belt Deflection

New

Used









Alternator

0.125 in

0.25 in









Power Steering or Idler

0.25 in

0.4375 in









Air Conditioning

0.3125 in

0.375 in









Air Pump

0.2187 in

0.25 in
