Ignition System › Ignition Coil › Locations
Powertrain ManagementLocations · page 1 of 3

Ignition Coil: Locations – diagram from the Powertrain Management chapter of the Plymouth Voyager V6-201 3.3L (1991) factory manual.

Diagram: Ignition Coil: Locations – Plymouth Voyager V6-201 3.3L (1991)

Ignition Coil: Locations

Ignition Coil And Coolant Temperature Sensor Location

  The Ignition Coil Unit is located on the intake manifold.
