G8 V6-3.6L (2008)
Fuse Block: Locations
Harness Routing Views
Body Front Wiring (3.6L, Left Hand Drive)
1 - Fuse Block - Underhood - X124
2 - Body Front Harness to RF Wheel Speed Sensor Connector - X161
3 - Electronic Brake Control Module (EBCM) Connector - A38/A116
4 - Transmission Control Module (TCM) Connector - A112
5 - Body Wiring Harness Connector 1 - X206
6 - Instrument Panel Wiring Harness Connector 3 - X200
7 - Instrument Panel Wiring Harness Connector 4 - X204
8 - Instrument Panel Wiring Harness Connector 5 - X207
9 - Instrument Panel Wiring Harness Connector 2 - X203
10 - Instrument Panel Wiring Harness Connector 1 - X104
11 - Theft Horn Connector - B9-X1 & B9-X2
12 - Windshield Wiper Motor Connector - M17
13 - Brake Fluid Level Switch Connector - S36
14 - Body Front Harness to LF Wheel Speed Sensor Connector - X160
15 - Right Chassis Rail Ground - G102
16 - Engine and Transmission Wiring Harness Connector 2 - X110
17 - Engine and Transmission Wiring Harness Connector 1 - X102
18 - Body Front to Front Fascia Wiring Harness Connector - X108
19 - Front Compartment Wiring Harness Connector 1 - X106
20 - Engine and Transmission Wiring Harness Connector 4 - X103
21 - Right Chassis Rail Ground - G101
Front of Vehicle/Engine Compartment Component Views
Component locator (LY7 - Gas, 6 Cylinder, 3.6L, SFI, V6)
