G8 V8-6.0L (2009)
7. Install a NEW park brake lever lower grip (4).
8. Install the park brake lever to park brake lever lower grip retaining screws (3).
9. Install the park brake lever spring and the park brake lever button (2).
10. Attach the park brake lever cable (5) to the park brake lever button (2).
Note: The park brake lever upper grip (1) is retained by clips. Make sure all the clips are aligned with the park brake lever lower grip (4) and are
engaged to avoid an induced rattle condition.
Note: This cable adjustment affects the release of the park brake, and could result in accidental release of the park brake.
11. Install a NEW park brake lever upper grip (1).
Installation Procedure
