Clutch Switch: Locations
- Make
- Pontiac
- Model
- Solstice
- Engine
- L4-2.4L
- Year
- 2007
- Section
- Starting System › Clutch Switch › Locations
Starting and ChargingLocations · page 1 of 3
Clutch Switch: Locations
Engine Electrical Component Views
Left Side of I/P
Left Side of I/P
1 - Brake Pedal Position Sensor
2 - Accelerator Pedal Position (APP) Sensor
3 - Data Link Connector (DLC)
4 - Data Link Connector (DLC) Resistor
5 - Clutch Pedal Position (CPP) Switch
6 - Clutch Start Switch
7 - C165
8 - C166
