Vibe L4-1.8L (2008)
Blower Motor: Locations
HVAC Component Views
A/C Compressor Clutch
1 - A/C Compressor Clutch Assembly
2 - A/C Compressor Assembly
3 - Snap Ring
4 - Snap Ring
5 - Clutch Washer
Refridgerant Pressure Switch
1 - Refridgerant Pressure Sensor
Recirculation Actuator
1 - Actuator Bolts
2 - Actuator Connector
3 - Recirculation Actuator
A/C Switch
