Steering Gear: Diagrams
Power Steering Gear Disassembled View
Power Steering Gear Disassembled View (FWD)
Power Steering Gear Disassembled View
1 - Bolt
2 - Bolt
3 - Bolt
4 - Bolt
5 - Steering Linkage Outer Tie Rod Cotter Pin
6 - Steering Linkage Outer Tie Rod Nut
7 - Steering Linkage Outer Tie Rod
8 - Steering Linkage Inner Tie Rod Nut
9 - Steering Gear Boot Clamp
10 - Steering Gear Boot
11 - Steering Gear Boot Clamp
12 - Steering Linkage Inner Tie Rod
13 - Steering Gear Housing
14 - Steering Linkage Inner Tie Rod
15 - Steering Gear Boot Clamp
16 - Steering Gear Boot
17 - Steering Gear Boot Clamp
18 - Steering Linkage Inner Tie Rod Nut
19 - Steering Linkage Outer Tie Rod
20 - Steering Linkage Outer Tie Rod Nut
21 - Steering Linkage Outer Tie Rod Cotter Pin
