911 Carrera 4 Cabriolet (997) F6-3.6L (2006)
/f6-3.6l/Page-306011.png)
View Of Vacuum Units
4. Unscrew fastening screws -arrows- for vacuum units.
View Of Ball Joints
5. Lever ball sockets from the ball heads.
6. Unclip solenoid valves from brackets and remove the entire hose assembly.
Intake Distributor Gasket
7. Remove intake-air distributor gaskets.
Screws For Throttle Body
8. Remove throttle body by unscrewing the four Torx screws (M6 x 50) -arrows-.
Sealing Ring For Throttle Body
9. Pull off the seal -arrow- from the throttle body.
