911 Targa 4S (997) F6-3.8L (2007)
Installing sealing ring for front halfshaft flange
3. Install halfshaft flange.
3.1.
Replace circlip -A- for the halfshaft flange. To do this, clamp the halfshaft flange in the vice with a hexagon-head bolt -B- and press the circlip
out with the new circlip -A-.
Replacing circlip
3.2.
Grease circlip -A- for easier fitting.
3.3.
Tap the halfshaft flange -arrow- into the final drive using a rubber hammer.
Tapping in halfshaft flange
Subsequent work
1. Install front drive shaft.
2. Check oil for front final drive and top up if necessary.
3. Install front underbody panelling.
4. Lower the vehicle.
