Female

Make

Rover

Model

400 Electrical Library

Year

1998 model year on

Section

C0025 › Female

ConnectorsFemale · page 1 of 2

Header joint

Female

ORANGE

Behind RH side of fascia

Cav	Col	CCT
1	GB	69
1	BY	70
1	GY	80
2	GB	69
2	BY	70
2	GY	80
3	GB	69
3	GY	80
4	GB	7
4	BY	70
4	GY	80
5	GW	69

Cav Col CCT

5 GR 70 5 GR 80 6 GW 69 6 GR 70 6 GR 80 7 GW 9 7 GR 70 7 GR 80 8 GY 69 8 GU 70 8 GU 80 9 GY 69 9 GU 70 9 GU 80

05 General
