Female
- Make
- Rover
- Model
- 400 Electrical Library
- Year
- 1998 model year on
- Section
- C0040 › Female
ConnectorsFemale
Diagnostic socket - LHD
Female
BLACK
Behind LH side of fascia
| Cav | Col | CCT |
|---|---|---|
| 1 | OU | 69 |
| 1 | OU | 79 |
| 3 | RU | 69 |
| 3 | RU | 79 |
| 4 | BS | 69 |
| 4 | B | 79 |
| 7 | UG | 9 |
| 7 | K | 79 |
| 15 | LGR | 4 |
| 15 | LGR | 36 |
| 16 | WR | 69 |
| 16 | P | 79 |
