Male
- Make
- Rover
- Model
- 400 Electrical Library
- Year
- 1998 model year on
- Section
- C0055 › Male
ConnectorsMale
Key-in switch
Male
BROWN
Under LH side of fascia
| Cav | Col | CCT |
|---|---|---|
| 1 | G | 42 |
| 1 | G | 42 |
| 1 | WB | 69 |
| 1 | WB | 79 |
| 3 | BW | 69 |
| 3 | BW | 79 |
| 4 | UW | 69 |
| 4 | UW | 79 |
| 6 | WR | 69 |
| 6 | P | 79 |
