Female
- Make
- Rover
- Model
- 400 Electrical Library
- Year
- 1998 model year on
- Section
- C0077 › Female
ConnectorsFemale
Header joint
Female
ORANGE
Behind RH headlamp
| Cav | Col | CCT |
|---|---|---|
| 1 | GB | 79 |
| 2 | GB | 79 |
| 3 | GB | 79 |
| 4 | GB | 79 |
| 5 | GW | 79 |
| 6 | GW | 79 |
| 7 | GW | 9 |
| 8 | GY | 79 |
| 9 | GY | 79 |
| 10 | GY | 79 |
| 11 | GR | 79 |
| Cav | Col | CCT |
|---|---|---|
| 12 | GR | 79 |
| 13 | GR | 79 |
| 14 | WG | 79 |
| 15 | WG | 79 |
| 16 | WG | 79 |
