Flex Plate: Specifications
Torque Specifications
First Pass In Sequence ............................................................................................................................................................................. 20 Nm (15 ft. lbs.).
Second Pass In Sequence ......................................................................................................................................................................... 50 Nm (37 ft. lbs.).
Final Pass In Sequence .......................................................................................................................................................................... 100 Nm (74 ft. lbs.).
