Astra L4-1.8L (2009)
Note: The spring of the main bracket is not secured and may fall down.
8. Remove the left sunshade support.
1. Remove the sunshade.
2. Pull out the main bracket wedge and remove the main bracket.
9. Remove the right sunshade.
1. Remove the 2 bolts.
2. Loosen the wiring harness plug insulating tape.
3. Disconnect the mirror lighting wiring harness plug.
Note: The spring of the main bracket is not secured and may fall down.
10. Remove the right sunshade support.
1. Remove the sunshade.
2. Pull out the main bracket wedge and remove the main bracket.
