Drive Belt: Testing and Inspection (page 2 of 3)
- Make
- Saturn
- Model
- Aura
- Engine
- V6-3.5L
- Year
- 2007
- Section
- Drive Belt
MaintenanceTesting and Inspection · page 2 of 3
Drive Belt: Service and Repair
Drive Belt Replacement
Removal Procedure
1. Remove the air cleaner assembly.
2. Remove the engine mount strut.
3. Install a breaker bar to the drive belt tensioner.
4. Rotate the drive belt tensioner counterclockwise to release the spring tension.
5. Remove the drive belt, if equipped with hydraulic power steering.
6. Remove the drive belt, if equipped with hydraulic power steering.
Installation Procedure
