Splash Guard: Service and Repair
Splash Shield Replacement - Engine
Removal Procedure
1. Raise and support the vehicle. Refer to Vehicle Lifting.
2. Remove the front fender liner.
3. Remove the air cleaner intake duct bolt.
4. Remove the push-in retainers from the engine splash shield. Remove the splash shield.
Installation Procedure
1. Install the engine splash shield by inserting the push-in retainers.
