Drive Belt: Testing and Inspection (page 2 of 3)
- Make
- Saturn
- Model
- ION
- Engine
- L4-2.4L
- Year
- 2007
- Section
- Drive Belt
MaintenanceTesting and Inspection · page 2 of 3
Drive Belt: Service and Repair
Drive Belt Replacement
Tools Required
J 44811 Accessory Belt Tensioner Unloader
Removal Procedure
1. Remove the engine splash shield.
2. Install the J44811 to the drive belt tensioner.
3. Using the J44811, rotate the tensioner counterclockwise in order to release the tensioner from the drive belt.
4. Remove the drive belt.
5. Slowly rotate the J44811 and the tensioner clockwise in order to allow the tensioner to rest.
6. Remove the J44811 from the drive belt tensioner.
Installation Procedure
