Drive Belt: Testing and Inspection (page 3 of 3)
- Make
- Saturn
- Model
- ION
- Engine
- L4-2.4L
- Year
- 2007
- Section
- Drive Belt
MaintenanceTesting and Inspection · page 3 of 3
1. Install and position the drive belt around all of the pulleys except for the drive belt tensioner.
2. Install the J44811 to the drive belt tensioner.
3. Using the J44811, rotate the tensioner counterclockwise.
4. Position the drive belt under the tensioner pulley.
5. Using the J44811, rotate the tensioner clockwise in order to seat the tensioner pulley onto the drive belt.
6. Install the engine splash shield.
