Relays and ModulesAntitheft System - Security Telltale Lamp ON/DTC B2960 · page 5 of 5
Antitheft System - Security Telltale Lamp ON/DTC B2960 (page 5 of 5) – Saturn L100 L4-2.2L VIN F (2001)

circuit. The specified procedure will determine the particular condition.

5.

Tests for an open in the Passlock(TM) sensor signal circuit, which may not set a DTC (B2958) under certain conditions.

6.

The presence of DTCs which begin with "U" indicate another module is not communicating. The specified procedure will compile all the available
information before tests are performed.

7.

The presence of DTC P0601, P0602, or P0604 indicates an internal fault in the PCM.

8.

The presence of DTC B1000 indicates an internal module fault.

9.

The presence of DTC P0562, P0563, or P0621 indicates a low or high voltage condition.

Parts Information:

Claim Information:

To receive credit for this repair during the warranty coverage period, submit a claim through the Saturn Dealer System for E7650 (Module, Ignition Lock
Cylinder (Housing) - R&R or Replace).

Disclaimer
