Workshop Manuals Factory service & repair Saturn
Saturn L200 L4-2.2L VIN F (2002)14 · Body and Frame
14 · Body & interior

Cross-Member: Specifications

Make
Saturn
Model
L Series L200
Engine
L4-2.2L VIN F
Year
2002
Section
Frame › Cross-Member › Specifications
Body and FrameSpecifications · page 1 of 5
background image

Cross-Member: Specifications



Crossmember Nut and Bolt

66 ft. lbs. + 60 degrees to 75 degrees







Rear Suspension Support-to-Body Bolts

66 ft. lbs. + 90 dgrees to 105 degrees







Suspension Support-to-Body Bolts

66 ft. lbs. + 45 degrees to 60 degrees
