xB L4-1.5L (1NZ-FE) (2004)
/Page-820002.png)
a. Slide the clip and disconnect the vacuum hose from the brake booster assy.
b. Remove the brake pedal return spring, the clip and the clevis pin.
c. Loosen the push rod clevis lock nut.
d. Remove the 4 nuts and push rod clevis.
e. Pull out the brake booster assy and the gasket.
8. INSTALL BRAKE BOOSTER ASSY
a. Install the brake booster assy and a new gasket.
b. Install the brake booster assy with the 4 nuts and push rod clevis.
Torque: 13 Nm (130 kgf-cm, 9 ft. lbs.)
