xB L4-1.5L (1NZ-FE) (2004)
![background image](/scion/xb/l4-1.5l_(1nz-fe)/Page-1375002.png)
b. Automatic Stop Position Operation Check
1. Connect the battery positive cable to terminal 1 of the connector and the battery negative cable to terminal 2.
NOTE: The body earth should be connected.
2. With the motor being rotated, disconnect terminal 1 (+B) and terminal 3 (+1) to stop the motor operation at any position other than the
automatic stop position.
3. Connect the battery positive cable to terminal 1. Check that the motor is restarted and automatically stops.
