Tire Pressure Module Service and Repair Components
Tire Pressure Module: Service and Repair
Removal
TIRE AND WHEEL: TIRE PRESSURE WARNING ECU: REMOVAL
REMOVAL
NOTE: Before removing the tire pressure warning ECU, read the registered transmitter ID of all wheels and write them down to use for
re-registration of transmitter ID See: Instrument Panel, Gauges and Warning Indicators/Tire Monitoring System/Testing and
Inspection/Programming and Relearning/Registration.
1. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY See: Body and Frame/Interior Moulding / Trim/Dashboard / Instrument
Panel/Service and Repair/Upper Instrument Panel/Removal
2. REMOVE TIRE PRESSURE WARNING ECU
(a) Disconnect the tire pressure warning ECU connector.
(b) Remove the screw and remove the tire pressure warning ECU.
