Leon Mk1
Installing Bowden cable |
Note
t | Before fitting cover, the area where the seal touches it must be cleaned. |
t | Under no circumstances must water be allowed to enter the swivel mechanism -2-. |
– | Locate drive -3- on towing bracket -1-. |
– | Counterhold bolts -11- and tighten hexagon nuts -9-. |
– | Turn rotating plate -7- a little and insert Bowden cable -5-. |
– | Fit cover -6- in place. |
– | Tighten bolts -8-. |
