Rear door trim with mechanical window lifter, installation
Rear door trim with mechanical window lifter, installation
Install in reverse order, noting the following:
  Caution
Cleanliness is of utmost importance when performing this work. Any dirt caused when removing or assembling will lead to additional time expenditure with subsequent work.

–  Fit the window handle to the winding assembly.
  Note
t  The assembly position with windows closed is: a = 45° ± 12°.
t  The -arrow- in the illustration represents the direction of travel.
  N70-0008
