Leon Mk1
Bodywork
Bodywork, exterior fitting work / Body front
Front wing, removing and installing
Wing dimensions
Wing dimensions
Wing dimensions
Separation between wings
Horizontal and vertical offset between the ends of the wings
a = 0 ± 2 mm
1 -
Soundproofing
q
Fixed with bolts and secured at the front in the lock carrier
1 -
Bolt
q
Twelve units
2 -
Clamped Ring
q
Four units
3 -
Bolt
q
Three units
