Poly-V belt without air conditioner compressor: Removing and installing

t	Removing → Anchor

t	Installing → Anchor

Check the tool and equipment equivalence table according to the applicability between Seat / VW / Audi / Skoda → Chapter

Special tools and workshop equipment required

t	Poly V-belt repair kit with assembly tools → Electronic spare parts catalogue

Removing

Note

The poly V-belt repair kit with tools contains tool -T10367- and illustrated instructions.

–	Fit the centre noise insulation -fasteners 1 ... 3-.

–	Fit the right noise insulation -fastening parts 1 ... 3-.

–	Cut through the Poly V-belt.

Installing

–	Proceed as described in illustrated instructions.

Note

The poly V-belt repair kit with tools contains tool -T10367- and illustrated instructions.

–	Fasten the front wheel housing liner in the front area again.

–	Fit the centre noise insulation -fastening parts 1 ... 3-.
