Forester F4-2.5L SOHC (2004)
6) Remove the front shoe hold down spring and pin with pliers.
7) Remove the strut and strut spring.
8) Remove the adjuster assembly from parking brake assembly.
9) Remove the brake shoe.
10) Remove the rear shoe hold-down spring and pin with pliers.
11) Remove the parking brake cable from parking brake lever.
12) Using a standard screwdriver, raise the retainer. Remove the parking brake lever and washer from brake shoe.
INSTALLATION
CAUTION: Be sure the lining surface is free from oil and grease contamination.
1) Apply brake grease to the following places.
Brake grease: Brake Grease (Part No. 003602002)
^
Six contact surfaces of shoe rim and back plate packing
^
Contact surface of shoe wave and anchor pin
^
Contact surface of lever and strut
^
Contact surface of shoe wave and adjuster assembly
^
Contact surface of shoe wave and strut
^
Contact surface of lever and shoe wave
2) Insert the primary side brake shoe into anchor pin groove.
3) Secure the brake shoe with shoe hold-down pin and cup.
