Forester F4-2.5L SOHC (2004)
4) Install the plate to anchor pin, and then assemble the primary return spring to anchor pin.
5) Install the parking brake cable to parking brake lever.
6) Assemble the strut and adjuster, and then secure the secondary side brake shoe with shoe holddown pin & cup.
NOTE:
^
Install the strut spring of both right and left wheel facing vehicle front.
^
Install the adjuster assembly with screw on left side.
7) Install the secondary return spring and adjusting spring.
8) Adjust the parking brakes.
9) Drive the vehicle for parking brake lining "break-in".
1) Drive the vehicle at about 35 km/h (22 MPH).
2) With the parking brake release button pushed in, pull the parking brake lever gently.
3) Drive the vehicle for about 200 meter (0.12 mile) in this condition.
4) Wait 5 to 10 minutes for the parking brake to cool down. Repeat this procedure once more.
5) After breaking-in, re-adjust the parking brakes.
