Forester F4-2.5L SOHC (2004)
4. Install the tensioner bracket.
Tightening torque: 25 Nm (2.5 kgf-m, 18.1 ft. lbs.)
5. Install the camshaft sprockets (LH) by using ST.
ST 18231AA010 CAMSHAFT SPROCKET WRENCH
NOTE: Also the CAMSHAFT SPROCKET WRENCH (499207100 can be used.
Tightening torque: 78 Nm (8.0 kgf-m, 57.9 ft. lbs.)
6. Install the belt idler No. 2.
Tightening torque: 39 Nm (4.0 kgf-m, 28.9 ft. lbs.)
7. Install the automatic belt tension adjuster which tension rod is held with pin.
8. Install the timing belt.
9. Install the V-belts.
10. Install the radiator.
INSPECTION
1. Check the water pump bearing for smooth rotation.
2. Check the water pump pulley for abnormalities.
3. Using a dial gauge, measure the impeller runout in thrust direction while rotating the pulley.
"Thrust" runout limit: 0.5 mm (0.020 inch)
