Forester F4-2.5L SOHC (2004)
NOTE:
^
"0" marks indicate the directions of residual unbalance.
^
Temporarily tighten the bolts by hand. Each bolt should be tightened to the specified torque in a crisscross fashion.
Tightening torque: 15.7 Nm (1.6 kgf-m, 11.6 ft. lbs.)
3. Remove the ST.
ST 499747100 CLUTCH DISC GUIDE
4. Install the transmission assembly. <Ref. to MT29, INSTALLATION, Manual Transmission Assembly.>
INSPECTION
CLUTCH DISC
1. Facing wear Measure the depth of rivet head from the surface of facing. Replace if facings are worn locally or worn down to less than the specified
value.
Depth of rivet head:
Limit of sinking 0.3 mm (0.012 inch)
NOTE: Do not wash the clutch disc with any cleaning fluid.
2. Hardened facing Correct by using emery paper or replace.
3. Oil soakage on facing Replace the clutch disc (A) and inspect the transmission front oil seal, transmission case mating surface, engine rear oil seal
