Forester F4-2.5L SOHC (2004)
NOTE: Confirm that the snap ring is completely fitted in shaft groove.
6. Install the cage, which was previously fitted, to inner race fixed upon shaft.
NOTE: Fit the cage with protruded part aligned with the track on inner race, and then turn by a half pitch.
7. Fill 80 to 90 g (2.82 to 3.17 oz) of specified grease into the interior of DOJ outer race.
8. Apply a coat of specified grease to the cage pocket and six balls.
9. Insert six balls into the cage pocket.
10. Align the outer race track and ball positions and place in the part where shaft, inner race, cage and balls are previously installed, and then fit outer
race.
11. Install the circlip in the groove on DOJ outer race.
NOTE:
^
Assure that the balls, cage and inner race are completely fitted in the outer race of DOJ.
^
Exercise care not to place the matched position of circlip in the ball groove of outer race.
^
Pull the shaft lightly and assure that the circlip is completely fitted in the groove.
12. Apply an even coat of the specified grease [20 to 30 g (0.71 to 1.06 oz)] to the entire inner surface of boot. Also apply grease to shaft.
13. Install the DOJ boot taking care not to twist it.
NOTE:
^
The inside of the larger end of DOJ boot and boot groove shall be cleaned so as to be free from grease and other substances.
^
When installing the DOJ boot, position the outer race of DOJ at center of its travel.
14. Put a new band through the clip and wind twice in alignment with band groove of boot.
15. Pinch the end of band with pliers. Hold the clip and tighten securely.
NOTE: When tightening the boot, exercise care so that air within the boot is appropriate.
