Forester F4-2.5L SOHC (2004)
16. Tighten the band by using ST.
ST 925091000 BAND TIGHTENING TOOL
NOTE: Tighten the band until it cannot be moved by hand.
17. Tap on the clip with the punch provided at the end of ST.
ST 925091000 BAND TIGHTENING TOOL
NOTE: Tap to an extent that the boot underneath is not damaged.
18. Cut off the band with an allowance of about 10 mm (0.39 inch) left from the clip and bend this allowance over the clip.
NOTE: Be careful so that the end of the band is in close contact with clip.
19. Fix up the boot on BJ in the same manner.
20. Extend and retract the DOJ to provide equal grease coating.
Rear Drive Shaft Inspection
INSPECTION
Check the removed parts for damage, wear, corrosion etc. If faulty, repair or replace.
1. DOJ (Double Offset Joint)
Check seizure, corrosion, damage, wear and excessive play.
2. Shaft
Check excessive bending, twisting, damage and wear.
3. BJ (Bell Joint)
Check seizure, corrosion, damage and excessive play.
4. Boot
Check for wear, warping, breakage or scratches.
5. Grease
Check for discoloration or fluidity.
