3. Remove clutch release lever sealing.

4. Remove clutch release lever retainer spring from clutch release lever pivot with a screwdriver by accessing it through clutch housing clutch release

lever hole. Then remove clutch release lever.

B: INSPECTION

Clutch Release Bearing

CAUTION:  Since this bearing is grease sealed and is of a nonlubrication type, do not wash with gasoline or any solvent when servicing the clutch.

1. Check the bearing for smooth movement by applying force in the radial direction.
