Impreza L Coupe AWD F4-2.2L SOHC (2001)
Alignment: Specifications
2500 cc
2200 cc
Sedan, Coupe
Wagon
OUTBACK
Coupe
AWD
AWD
AWD
AWD
Front Camber ( tolerance ± 0°30' )
0°
0°
0°
-0°25'
Caster (common difference ± 1°)
3°
3°
3°
3°05'
Toe-in mm (in)
0 ± 3 (0 ± 0.12) Toe-in angle: -0°09'
[when toe-in is -3 (-0.12)]
Toe-out angle: 0°09' [when toe-out
is 3 (0.12)]
Kingpin angle
14°
14°
14°
14°
Wheel arch height [tolerance: +12 / -24 mm mm (in) 391 (15.39)
391 (15.39)
394 (15.51)
371 (14.61)
(+0.047 / -0.94 in)]
Rear
Camber ( tolerance ± 0°45' )
-0°55'
-0°55'
-0°55'
-1°10'
Toe-in mm (in)
0 ± 3 (0 ± 0.12) Total toe angle 0° ± 18'
Wheel arch height [tolerance: ± 10 mm (±
mm (in) 379 (14.92)
379 (14.92)
386 (15.20)
368 (14.49)
0.39 in)]
Thrust angle (tolerance: 0° ± 20' )
0°
0°
0°
0°
