Subaru Justy L3-1189cc 1.2L (1987)|Filters > < Timing Belt|Service and Repair|Page 698

Justy L3-1189cc 1.2L (1987)

Page 1
background image

Fig. 55  Drive Belt Routing & Tension Data
