Timing Belt: Service and Repair
REMOVAL
1) Loosen the bolts which secure the alternator, and remove the V-belt.
2) Using CRANK & CAMSHAFT PULLEY WRENCH (499205500), loosen the crankshaft bolts.
NOTE: Do not remove the crankshaft bolts.
3) Turn the crankshaft pulley until the #3 piston is set at TDC.
4) Remove the bolts which secure the crankshaft pulley, and remove the crankshaft pulley.
NOTE: Insert a 'T" wrench into the access hole in the wheelhouse to remove the bolts.
5) Remove the cam belt cover 2.
