Legacy F4-2.5L SOHC (2003)
3. Follow the wheel alignment gauge operation manual to measure the camber angle.
NOTE: Refer to the "SPECIFICATIONS" for the camber values.
Front Camber Adjustment
1. Loosen two self-locking nuts located at lower front portion of strut.
CAUTION: When adjusting bolt needs to be loosened or tightened, hold its head with a wrench and turn self-locking nut.
Discard loosened self-locking nut and replace with a new one.
2.
Turn camber adjusting bolt so that camber is set at the specification.
NOTE: Moving the adjusting bolt by one scale graduation changes camber by approximately 0° 10'.
