Legacy F6-3.0L (2005)
Splash Guard: Service and Repair
FRONT UNDER COVER
Under Cover
REMOVAL
1. Lift-up the vehicle.
2. Remove the clips (A) in front fender and bolts (B), and then remove the front under cover.
-
Large type
-
Small type
INSTALLATION
Install in the reverse order of removal.
Tightening torque: 14 N.m (1.42 kgf-m, 10.3 ft-lb)
