Legacy Brighton Wagon AWD F4-2.5L SOHC (2000)
2) Using ST and a puller (common hand tool), remove bearing inner race.
ST1 399520105 SEAT
ST2 927080000 HUB STAND
CAUTION:
^
Do not remove hub unit bearing unless damaged.
^
Do not re-use hub unit bearing after removal.
3) Using ST press hub bolt out. ST 927080000 HUB STAND
CAUTION: Be careful not to hammer hub bolts. This may deform hub.
C: INSPECTION
Check the removed parts for wear and damage. If defective, replace with new ones.
CAUTION: It a bearing is faulty, replace it as a hub unit bearing.
D: ASSEMBLY
1) Using ST, press new hub bolt into place.
CAUTION:
Ensure hub bolt closely contacts hub.
^
Use a 12 mm (0.47 in) hole in the ST to prevent hub bolt from tilting during installation.
ST 927080000 HUB STAND
