Outback F4-2.5L SOHC (2005)
4. Install the transmission assembly.
INSPECTION
NOTE: The illustration below is for Turbo model. However, perform the same procedure for Non-turbo model.
CAUTION: Since this bearing is grease-sealed and non-lubrication type, do not wash it with gasoline or any solvent.
1. Damage on sliding surface of facing and ring gear:
If defective, replace the flywheel.
2. Smoothness of rotation
Rotate the ball bearing while applying pressure in thrust direction.
3. If noise or excessive play is noted, replace the flywheel.
